Product Parameters
Model | KHY 8000TL-48SY | KHY 10000TL-48SY | KHY 12000TL-48SY |
INVERTER OUTPUT | |||
Rated Output Power | 8800W | 10000W | 12000W |
Max.Peak Power | 16000VA | 20000VA | 24000VA |
Rated Output Voltage | 230Vac single-phase / three-phase (parallel) | ||
Capacity of Motor Load | 5HP | 6HP | |
Output Frequency | 50/60Hz | ||
Number of Parallel | 1~6 units | ||
AC OUTPUT ( GRID) | |||
Rated Output Power | 8800W | 10000W | 12000W |
Max. Apparent Power | 8800VA | 10000VA | 12000VA |
Max. Output Current | 40Aac | 43.5Aac | 54.5Aac |
Rated Output Voltage | 230Vac | ||
THDI | <3% | ||
Power Factor | 0.8 leading to 0.8 lagging | ||
Frequency | 50/60HZ | ||
BATTERY | |||
Battery Types | Lead-acid/Li-ion/User Defned | ||
Rated Battery Voltage | 48V | ||
Battery Voltage Range | 40-60Vdc | ||
Max.Generator ChargingCurrent | 60A | ||
Max. Grid Charging Current | 120A | ||
Max.PV Charging Current | 200A | ||
Max.Hybrid Charging Current | 200A | ||
PV INPUT | |||
Num. of MPPT Trackers | 2 | ||
Max.PV Array Power | 5500W+5500W | 6600W+6600W | |
Max. Input Current | 22A+22A | ||
Max,.Voltage of Open Circuit | 800Vdc+800Vdc | ||
MPPT Voltage Range | 125-425Vdc | ||
MAINS/GENERATOR INPUT | |||
Input Voltage Range | 90-280Vac | ||
Frequency Range | 50/60Hz | ||
Bypass Overload Curent | 63A | ||
EFFICIENCY | |||
MPPT Tracking Effciency | 99.90% | ||
Max. Effciency | 97.50% | ||
European Effciency | 97.00% | ||
GENERAL | |||
Dimensions | 670*440*240mm | ||
Weight | 37kg | ||
Protection Degree | IP65 | ||
Operating Temperature Range | -25-60℃,>45°C derated | ||
Humidity range | 0~100% | ||
Cooling Method | Forced air cooling | ||
COMMUNICATION | |||
Embedded Interfaces | RS485/CAN/USB/Dry contact | ||
External Module (optional) | Wi-Fi/ GPRS | ||
CERTIFICATION | |||
Safety | IEC62109-1,IEC62109-2 | ||
EMC | EN61000-6-1,EN61000-6-3,FCC15 classB | ||
RoHS | Yes |
Product About
With software and hardware security protection
Multiple safety approvals
Industrial design with a modern aesthetic look
Product Features
Easy to install and simple to use
Up to 200A charging current
Supports Li-ion battery BMS communication
Exclusive Li-ion battery BMS dual activation
Time-slot function to save cost with peak-valley
Advanced MPPT with up to 99.9% efficiency
Up to 22A*2 PV input current
Output high-quality pure sine wave AC power
With lP65 protection degree
Appliration Scenarios
Simple - efficient - safe - reliable
