Product Parameters
Model | KHY 8000TL3-48TX | KHY 10000TL3-48TX | KHY 12000TL3-48TX |
INVERTER OUTPUT | |||
Rated Output Power | 8000W | 10000W | 12000W |
Max.Peak Power | 16000VA | 20000VA | 24000VA |
Rated Output Voltage | 230/400Vac,three-phase | ||
Capacity of Motor Load | 5HP | 6HP | 6HP |
Rated Frequency | 50/60Hz | ||
Output Waveform | pure sine wave | ||
Switching Time | 10ms(typical) | ||
BATTERY | |||
Battery Types | Li-ion/Lead-Acid/User Defned | ||
Rated Battery Voltage | 48Vdc | ||
Voltage Range | 40-60Vdc | ||
Max. PV Charging Current | 180A | 220A | 260A |
Max. Utility / Generator Charging Current | 100A | 120A | 120A |
Max. Hybrid Charging Current | 180A | 220A | 260A |
PV INPUT | |||
No. of MPPT | 2% | ||
Max.Input Power | 6000WV/6000WV | 7500W17500W | 9000W/9000W |
Max. Input Current | 22AV22A | ||
Max.Open-circuit Voltage | 800Vdc/800vdc | ||
MPPT Operating Voltage Range | 200-650Vdc/200-650Vdc | ||
UTILITY/GENERATOR INPUT | |||
Input Voltage Range | phase voltage 170~280V,line voltage 305~485V | ||
Input Frequency Range | 50/60Hz | ||
Bypass Overload Curent | 63A | ||
EFFICIENCY | |||
MPPT Tracking Effciency | 99.90% | ||
Max. Battery Inverter Effciency | ≥92% | ||
European Effciency | 97.20% | 97.50% | 97.50% |
GENERAL | |||
Dimensions | 620*445*130mm | ||
Weight | 27kg | ||
Protection Degree | IP20,indoor only | ||
Ambient Temp | -10~55℃,>45℃℃ derated | ||
Noise | <60dB | ||
Cooling Method | air cooling | ||
COMMUNICATION | |||
Internal Interface | RS485/CAN/USB/Dry contact | ||
External Module (optional) | Wi-Fi/ GPRS | ||
CERTIFICATION | |||
Safety | IEC62109-1,IEC62109-2 | ||
EMC | EN61000-6-1,EN61000-6-3,FCC15 classB | ||
RoHS | Yes |
Product About
Advanced MPPT technology with up to 99.9% efficiency
Up to 22+22A PV input current
Outputs high quality pure sine wave Ac power
Product Features
Up to 72kW load power for most household needs
Comprehensive security from hardware to software
Support Li-ion battery BMS communication
Exclusive Li-ion battery BMS dual activation
Time-slot function to save cost
Multiple safety certifications
Industrial design with a modern aesthetic look
Easy to install and simple to use
Up to 260A charging current
Appliration Scenarios
Simple - efficient - safe - reliable
