Product details of the on grid inverters
Product Description
We use on grid inverters material imported from abroad. The product meets the strict quality standards in the global market. With strong R&D strength and stable development, Shenzhen Kangweisi Technology Co., Ltd. has ensured that every product it brings to the market has reliable quality.
Product Parameters
Datasheet |
MAX 185KTL3-X HV |
MAX 216KTL3-X HV |
MAX 250KTL3-X HV |
MAX 253KTL3-X HV |
No. Of MPP Trackers |
9 |
9 |
12 |
15 |
AC Nominal Power |
185KW |
216KW |
250KW |
253KW |
Max. AC Apparent Power |
185KVA@30°C |
216KVA@30°C |
250KVA@30°C |
253KVA@30°C |
175KVA@40°C |
200KVA@40°C |
230KVA@45°C |
230KVA@45°C |
|
160KVA@50°C |
192KVA@50°C |
220KVA@50°C |
220KVA@50°C |
|
Max. Output Current |
133.5A |
155.9A |
180.4A |
182.6A |
European Efficiency |
98.70% |
98.70% |
98.70% |
98.50% |
Weight |
95kg |
95kg |
99kg |
109kg |
Protection Degree |
IP66 |
IP66 |
IP66 |
IP66 |
Relative Humidity |
0-100% |
0-100% |
0-100% |
0-100% |
Display |
LED/WIFI+APP |
LED/WIFI+APP |
LED/WIFI+APP |
LED/WIFI+APP |
Features
Highly efficient power generation
- Maximum conversion efficiency of 99 per cent
- Maximum 15-channel MPPT design, adapting to complex application scenarios.
- Maximum MPPT input current of 30A, suitable for high power modules.
Save cost of electricity
- Support string two-convergence one access, save DC cable cost.
- Support large diameter aluminium cable access, saving AC cable cost.
- Support PLC communication, saving communication cable and construction cost.
Safe and Reliable
- AC and DC secondary lightning protection
- IP66 protection level
- String monitoring and IV curve scanning, accurate positioning of abnormal strings.
- Optional PID function
Appliration Scenarios
Simple - efficient - safe - reliable
Company Advantage
• Our company is provided with natural resources, superior geographical condition, developed information and convenient transportation.
• Kangweisi was built in After years of integrity management, we have now become a modern enterprise with strong strength and talents.
• Kangweisi's professional R&D talents and professional after-sales service talents serve as the motivation for our company's long-term development.
• Our company has established a comprehensive product supply and after sales service system. To enhance sense of relying for us, we are persevering in offering thoughtful service for every customer.
Kangweisi's are of good quality and favorable price. Please contact us for order.
