Product details of the lithium battery supplier
Quick Overview
Kangweisi lithium battery supplier is designed in accorance with the basic production standard. It has a complete life cycle and high performance. The lithium battery supplier produced by our company is widely used. The integrity, strength and product quality of Kangweisi have been recognized by the industry.
Product Information
Next, the details of lithium battery supplier are shown for you.
Product Parameters
Items |
K-665.6V400AH |
Nominal voltage |
665.6V |
Nominal capacity |
400Ah |
Nominal energy |
266.24kWh |
Usable energy |
266kWh |
Max. voltage range |
603V~738V |
Charge voltage |
738V |
Float voltage |
730V |
Recommend charge current |
200A |
Max. charge current |
400A |
Recommend discharge current |
400A |
Max. discharge current |
1200A |
Communication |
RS485 /CAN |
Peak discharge current |
200~400A@3mins | 500~1200A@3S |
IP rating |
IP20 |
Cycle life |
≥4000 cycles |
Net weight |
~780kg |
Dimension(W*H*D) |
600*800*2000mm*4 |
Cell type |
Lithium-iron phosphate (LiFePO4) |
Design life |
15years |
Operation temperature |
-10~50℃ (14~122℉) |
Storage temperature |
-10~45℃ (14~113℉) |
Relative humidity |
5%~90%, No condensation |
Install altitude |
=3000m |
Install location |
Indoor |
Installation |
Wall mounted/ Floor mounted/ Stack/ Rack mounted |
Certification |
IEC62619 / UN38.3 / CE / CEC |
Product Features
Safe & Reliable
High safety LiFePO4 battery.
Compliance with IEC62619, UN38.3, CE, .
Modular
Support up to 32 units in parallel, scale from 5 kWh to 300kWh configuration without
external controller.
Ultra performance
More than 4000 cycles, self-developed
BMS/Cell/Pack to ensure best quality.
Compact & Flexible
3U(133.5mm) standard height design.
Optional bracket kits for different installation senarios.
Compatibility
Compatible with most hybrid/battery inverter in self- consumption, back-up andoff-grid applications.
Intellegence
Strong pre-charge and balancing capability.
Remote data history & firmware upgrading function via T-smart Cloud platform.
Appliration Scenarios
Simple - efficient - safe - reliable
Company Information
Shenzhen Kangweisi Technology Co., Ltd. (Kangweisi) is a professional company. The main products are Our company wholeheartedly provides customers with advanced, high quality and cost-effective services. Sincerely welcome customers who have needs to contact us for negotiation. I hope we can work together to create a brilliant future.
