Model:
Growatt MAX 185~250KTL3-X HV
Max.Power:
185kw-250kw
Output Voltage:
EU tandard
Certificate:
TUV, ETL, ISO, CE
Payment:
T/T, L/C, Western Union
Inquiry

Product details of the on grid inverters


Product Description

on grid inverters pursues best performance and perfect design. The product will not be delivered until the product quality is high. The reliable quality of the product ensures stable development prospects.

Product Parameters

Datasheet

MAX 185KTL3-X HV

MAX 216KTL3-X HV

MAX 250KTL3-X HV

MAX 253KTL3-X HV

No. Of MPP Trackers

9

9

12

15

AC Nominal Power

185KW

216KW

250KW

253KW

Max. AC Apparent Power

185KVA@30°C

216KVA@30°C

250KVA@30°C

253KVA@30°C

175KVA@40°C

200KVA@40°C

230KVA@45°C

230KVA@45°C

160KVA@50°C

192KVA@50°C

220KVA@50°C

220KVA@50°C

Max. Output Current

133.5A

155.9A

180.4A

182.6A

European Efficiency

98.70%

98.70%

98.70%

98.50%

Weight

95kg

95kg

99kg

109kg

Protection Degree

IP66

IP66

IP66

IP66

Relative Humidity

0-100%

0-100%

0-100%

0-100%

Display

LED/WIFI+APP

LED/WIFI+APP

LED/WIFI+APP

LED/WIFI+APP

Features

Highly efficient power generation

- Maximum conversion efficiency of 99 per cent

- Maximum 15-channel MPPT design, adapting to complex application scenarios.

- Maximum MPPT input current of 30A, suitable for high power modules.

Save cost of electricity

- Support string two-convergence one access, save DC cable cost.

- Support large diameter aluminium cable access, saving AC cable cost.

- Support PLC communication, saving communication cable and construction cost.

Safe and Reliable

- AC and DC secondary lightning protection

- IP66 protection level

- String monitoring and IV curve scanning, accurate positioning of abnormal strings.

- Optional PID function
