Solar System Equipment Suppliers 30KW/50KW/100KW/200KW/300KW by Kangweisi
Product Parameters
|
Items |
Configuration |
||||||
|
Model No. |
KWS30K-HY |
KWS50K-HY |
KWS100K-HY |
KWS150K-HY |
KWS250K-HY |
KWS500K-HY |
|
|
Solar Panel |
Quantity |
68 units |
119 units |
238 units |
340 units |
595 units |
1190 units |
|
Model |
KWS455M-72HPH (Mono) |
||||||
|
Max Power |
455W |
Size |
2094*1038*35mm |
||||
|
Voc |
49.8V |
Vmp |
41.1V |
||||
|
Isc |
11.61A |
Imp |
11.08A |
||||
|
Hybrid Inverter |
Quantity |
1 unit |
1 unit |
1 unit |
1 unit |
1 unit |
1 unit |
|
Model |
BPS30 |
BPS50 |
BPS100 |
BPS150 |
BPS250 |
BPS500 |
|
|
Max PV Power |
60/120KW |
120/180/240KW |
300/360KW |
600/660/720KW |
|||
|
MPPT Operating Voltage |
200V-850VDC |
||||||
|
Battery Voltage |
150V-850V |
420V-850V |
500V-850V |
||||
|
AC Voltage |
3P+E, 4wires , 400V |
||||||
|
Lithium Battery |
Model |
KWS-HV series |
|||||
|
Battery Voltage Range |
150~850V |
420~850V |
500~850V |
||||
|
Battery Bank Capacity (customized) |
60KWH |
98.4KWH |
196.8KWH |
295.2KWH |
545KWH |
1091KWH |
|
|
Battery Bank Capacity (90% DOD) |
54KWH |
88.56KWH |
177.12KWH |
265.68KWH |
490.5KWH |
981.9KWH |
|
|
BOS |
Battery Combiner Box |
1 set |
|||||
|
Mounting Brackets |
1 set |
||||||
|
DC Combiner Box |
4 in 1out |
7 in 2 out |
14 in 2 out |
20 in 3 out |
14 in 2 out |
20 in 3 out |
|
|
PV Cable 4mm 2 |
400m |
800m |
1600m |
2200m |
1600m |
2200m |
|
|
DC Breakers |
Optional |
||||||
|
MC4 Connectors |
20 pairs |
26 pairs |
50 pairs |
70 pairs |
50 pairs |
70 pairs |
|
Product Introduction
Energy storage system for solar power (ESS) refers to the device of converting electrical energy from power systems into a form that can be stored for converting back to electrical energy when needed.
30kw-500kw System Solution + 100Kwh-500kwh Customized Solution # Lead Acid, Gel # Lithium Battery Back Up.
Product Features
Commercial Hybrid systems is like one micro-grid power station , it is working for villas , office , hospital , school or big house , providing stable electricity power by renewable energy from PV , when the utility is abnormal , the ESS runs in off grid or on grid mode and provides stable power for loads . You can sell extra solar power to electricity company or store it in battery bank according to your investment plans.
Appliration Scenarios
Simple - efficient - safe - reliable
Company Advantages
· Kangweisi
· The quality of the product meets both the quality standards and the customer's expectation.
· Our solar system equipment suppliers are popular overseas.
Company Features
· Shenzhen Kangweisi Technology Co., Ltd. excels in the manufacture of quality solar system equipment suppliers.
· Our company has a dedicated product development team. They can discover the exact needs of customers while balancing engineering and manufacturing constraints to provide innovative solutions.
· Shenzhen Kangweisi Technology Co., Ltd. provides customers with excellent products and services. Inquire online!
Application of the Product
Kangweisi's solar system equipment suppliers is widely used in various scenes.
Kangweisi insists on providing customers with one-stop overall solution from the customer's point of view.
