On Grid Solar Inverter Western Union MID 25-40KTL3-X Kangweisi Company
Product details of the on grid solar inverter
Product Overview
on grid solar inverter is one of the factors that Shenzhen Kangweisi Technology Co., Ltd. emphasizes during material selection. More convenience for you with our on grid solar inverter. It can be provided with required print and size as we have the skills and experience.
Product Description
The on grid solar inverter produced by Kangweisi is better than the previous generation. The specific performance is as follows.
6KW Off-Grid Solar Power System
|
Datasheet |
MID 25KTL3-X1 |
MID 30KTL3-X |
MID 33KTL3-X |
MID 36KTL3-X |
MID40KTL3-X |
|
Input Data (DC) |
|||||
|
Max. recommended PV power (for module STC) |
37500W |
45000W |
49500W |
54000W |
60000W |
|
Max. DC voltage |
1100V |
||||
|
Start Voltage |
250V |
||||
|
Normal Voltage |
600V |
||||
|
MPPT voltage range |
200-1000V |
||||
|
No. of MPP trackers/strings per MPP tracker |
3 |
3 |
3 |
4 |
4 |
|
Max.input current per MPP tracker |
26A |
||||
|
Max. short-circuit current per MPP tracker |
32A |
||||
|
Output Data (AC) |
|||||
|
Rated AC output power |
25000W |
30000W |
33000W |
36000W |
40000W |
|
Max. AC apparent power |
27700VA |
33300VA |
36600VA |
39600VA |
44000VA |
|
Nominal AC voltage(range*) |
220V/380V, 230V/400V (340-440V) |
||||
|
AC grid frequency;(range*) |
50/60 Hz (45-55Hz/55-65 Hz) |
||||
|
Max. output current |
40A |
50.5A |
55.5A |
60.0A |
66.6A |
|
Adjustable power factor |
0.8 leading - 0.8 lagging |
||||
|
THDi |
<3% |
||||
|
AC grid connection type |
3W+N+PE |
||||
|
Efficiency |
|||||
|
Max.efficiency |
98.8% |
||||
|
European efficiency |
98.5% |
||||
|
MPPT efficiency |
99.9% |
||||
|
General Data |
|||||
|
Dimensions (W / H / D) |
580/435/230mm |
||||
|
Weight |
29.5kg |
29.5kg |
29.5kg |
30.5kg |
30.5kg |
|
Self-Consumption (night) |
<1W |
||||
|
Operating temperature range |
–25 °C ... +60 °C |
||||
|
Topology |
Transformerless |
||||
|
Cooling |
Smart air cooling |
||||
|
Protection degree |
IP65 |
||||
|
Relative Humidity |
0~100% |
||||
|
Altitude |
4000m |
||||
|
DC connection |
H4/MC4(Optional) |
||||
|
AC connection |
Cable gland+OT terminal |
||||
|
Display |
OLED+LED/WIFI+APP |
||||
|
Interfaces: RS485 / USB /WiFi/ GPRS / RF/ LAN |
Yes/Yes /Optional/Optional/Optional/Optional |
||||
|
Warranty: 5 years / 10 years |
Yes/Optional |
||||
Product Features
Efficient Power Generation
- 3/4 way MPPT
- DC overmatching 1.5 times
- 32A high current MPPT, suitable for 182/210 modules.
- Maximum conversion efficiency of 98.8%
Safe and Reliable
- Built-in AC/DC secondary lightning protection
- IP66 protection grade
- Intelligent air-cooling
Intelligent monitoring and maintenance
- High precision string monitoring
- Intelligent IV curve scanning
- Multiple monitoring methods, intelligent one-key diagnosis
Appliration Scenarios
Simple - efficient - safe - reliable
Company Advantages
Shenzhen Kangweisi Technology Co., Ltd. mainly exports on grid solar inverter with high quality to all over the world. Kangweisi has mature production technology, excellent team and strict quality control system, so that it can produce high quality products. We have a clear commitment to sustainable development. We work hard to reduce the production waste and pollution in the course of our operations.
Consulting and order from friends of all walks of life are welcomed!
